130 ACF5000 FTIR ANALYZER SYSTEM | OI/ACF5000-EN REV. A
User pages
In addition to the system pages, the user can set up so-called user pages
(see page 134).
Function blocks as sources
The values of all the function blocks in the system can be configured as a
source for the display. The source of the display of value inputs or key en-
tries is also a function block that was created when configuring the display
elements. The display of the function block value is independent of the other
links of the function block.
All sample components, auxiliary quantities, current outputs and current in-
puts exist as function blocks in the system, i.e., all of these measured quanti-
ties are displays of function blocks in the system. Technical Information
"Function blocks – Descriptions and configuration" contains complete infor-
mation on the "Function block" concept as well as detailed descriptions of the
individual function blocks.
Display element positioning on the screen
The display elements can be represented in two sizes. A maximum of three
large and six small display elements can be represented on a page. Large
and small display elements can be mixed with each other. The positions are
numbered as shown in the following figure. The numbering of the positions
corresponds to the arrangement of the number keys next to the display.
Views
The following views are available for screen configuration:
the display overview (see page 131),
the page overview (see page 132) and
the parameter overview (see page 133)
.
7
4
1
9
6
3
8
5
2
