Actual signals and parameters 195
1606 LOCAL LOCK Disables entering the local control mode or selects the
source for the local control mode lock signal. When local
lock is active, entering the local control mode is disabled
(LOC/REM key of the panel).
NOT SEL
NOT SEL Local control is allowed. 0
DI1 Local control mode lock signal through digital input DI1.
Rising edge of digital input DI1: Local control disabled.
Falling edge of digital input DI1: Local control allowed.
1
DI2 See selection DI1.2
DI3 See selection DI1.3
DI4 See selection DI1.4
DI5 See selection DI1.5
ON Local control is disabled. 7
COMM Fieldbus interface as the source for the local lock, ie Control
word 0301 FB CMD WORD 1 bit 14. The Control word is
sent by the fieldbus controller through the embedded
fieldbus (Modbus) to the drive. For the Control word bits,
see section DCU communication profile on page 307.
Note: This setting applies only for the DCU profile.
8
DI1(INV) Local lock through inverted digital input DI1. Rising edge of
inverted digital input DI1: Local control allowed. Falling edge
of inverted digital input DI1: Local control disabled.
-1
DI2(INV) See selection DI1(INV).-2
DI3(INV) See selection DI1(INV).-3
DI4(INV) See selection DI1(INV).-4
DI5(INV) See selection DI1(INV).-5
1607 PARAM SAVE Saves the valid parameter values to the permanent
memory.
Note: A new parameter value of a standard macro is saved
automatically when changed from the panel but not when
altered through a fieldbus connection.
DONE
DONE Saving completed 0
SAVE... Saving in progress 1
All parameters
No. Name/Value Description Def/FbEq
