Fault tracing 325
1003 PAR AI SCALE
(6320)
0307 bit 15
Incorrect analog input
AI signal scaling
Check parameter group 13 ANALOG
INPUTS settings. Check that following
applies:
• 1301 MINIMUM AI1 <
1302 MAXIMUM AI1
• 1304 MINIMUM AI2 <
1305 MAXIMUM AI2.
1004 PAR AO SCALE
(6320)
0307 bit 15
Incorrect analog output
AO signal scaling
Check parameter group 15 ANALOG
OUTPUTS settings. Check that
following applies:
• 1504 MINIMUM AO1 <
1505 MAXIMUM AO1.
1006 PAR EXT RO
(6320)
0307 bit 15
Incorrect extension
relay output
parameters
Check parameter settings. Check that
following applies:
• MREL relay output extension
module is connected to the drive.
• 1402…1403 RELAY OUTPUT 2 …
RELAY OUTPUT 3 and 1410
RELAY OUTPUT 4 have non-zero
values.
See MREL-01 relay output extension
module user's manual
(3AUA0000035974 [English]).
1012 PAR PFC IO 1
(6320)
0307 bit 15
I/O configuration for
PFC not complete
Check parameter settings. Following
must apply:
• There are enough relays
parameterized for PFC.
• No conflict exists between
parameter group 14 RELAY
OUTPUTS, parameter 8117 NR OF
AUX MOT and parameter 8118
AUTOCHNG INTERV.
1013 PAR PFC IO 2
(6320)
0307 bit 15
I/O configuration for
PFC not complete
Check parameter settings. Following
must apply:
• The actual number of PFC motors
(
parameter 8127 MOTORS)
matches the PFC motors in
parameter group 14 RELAY
OUTPUTS and parameter 8118
AUTOCHNG INTERV.
1014 PAR PFC IO 3
(6320)
0307 bit 15
I/O configuration for
PFC not complete.
The drive is unable to
allocate a digital input
(interlock) for each
PFC motor.
See parameters 8120 INTERLOCKS
and 8127 MOTORS.
1015 PAR USER
DEFINED U/F
(6320)
0307 bit 15
Incorrect voltage to
frequency
(U/f) ratio voltage
setting.
Check parameter 2610 USER
DEFINED U1…2617 USER DEFINED
F4 settings.
CODE FAULT CAUSE WHAT TO DO
