326 Fault tracing
1016 PAR USER LOAD C
(6320)
0307 bit 15
Incorrect user load
curve parameter
setting
Check parameter settings. Following
must apply:
• 3704 LOAD FREQ 1 <
3707 LOAD FREQ 2 <
3710 LOAD FREQ 3 <
3713 LOAD FREQ 4 <
3716 LOAD FREQ 5
• 3705 LOAD TORQ LOW 1 <
3706 LOAD TORQ HIGH 1
• 3708 LOAD TORQ LOW 2 <
3709 LOAD TORQ HIGH 2
• 3711 LOAD TORQ LOW 3 <
3712 LOAD TORQ HIGH 3
• 3714 LOAD TORQ LOW 4 <
3715 LOAD TORQ HIGH 4
• 3717 LOAD TORQ LOW 5 <
3718 LOAD TORQ HIGH 5.
1017 PAR SETUP 1
(6320)
0307 bit 15
It is not allowed to use
frequency input signal
and frequency output
signal simultaneously.
Disable frequency output or frequency
input:
• change transistor output to digital
mode (value of parameter 1804 TO
MODE = DIGITAL), or
• change frequency input selection to
other value in parameter groups
11 REFERENCE SELECT,
40 PROCESS PID SET 1,
41 PROCESS PID SET 2 and
42 EXT / TRIM PID.
