Planning the cabinet installation
24
Layout examples, door closed
1a Air inlet for the converter module
1b Air inlet for the other equipment
2a Air outlet for the converter module
2b Air outlet for the other equipment
2c Air outlet for the converter module and the
other equipment, an extra exhaust fan
3 Converter control panel (connected to the
RMIO board in the RDCU unit inside the
cabinet)
4 Contactor control switch and emergency
stop switch (connected to the contactor
control circuit inside the cabinet)
5 Operating handle of the disconnector
3
4
5
1a
1b
IP 54
3
4
5
1a
1b
1a
IP 22
2c
2b
Roof air flow viewed from top
1a
2a
