Mechanical installation of non-pre-assembled units (ACS800-04M)
58
Item packages of frame size R7 with busbars on the long side
ACS800-04M of frame size R7 with busbars on the long side
Package Parts Assembling drawing / reference to instruction
ProE code 64770306 D
Basic unit (type code ACS800-0M4-xxxx-x+H354+H355)
-
Refer to section Assembling procedure for units with
busbars on the long side (+H354) on page 73.
Drive control unit
(RDCU)
See RDCU Drive Control Unit Hardware Manual
[3AFE64636324 (English)].
Drive module
Front
RDCU drive control unit
