… 5 Product identification
… Name plate
Warning label concerning pressurized enclosure
• This housing may contain inert gas and may pose a
suffocation hazard.
• This housing contains a 3 V lithium battery.
• This housing must not be opened when a hazardous
atmosphere may be present. After opening the housing, the
power supply must not be restored until the housing has
been purged for 3 minutes with a flow rate of 20 l/min.
• After opening the housing, the power supply must not be
restored until the combustible dust accumulated in the
housing has been removed.
Name plate ATEX / IECEx, Zone 2
Transmitter unit
Receiver unit
1
Manufacturer
2
Serial number
3
Production date
4
Ex marking
5
Warning: laser class 1
6
Warning: do not open while
energized.
7
Warning – Risk of explosion: de-
energize before opening.
8
Sample component
9
Ambient temperature
0
Power supply
k
Project number
l
Type designation / model
m
Production number
Figure 14: Name plate AO2000-LS25 (example, ATEX / IECEx version, Zone 2)
LS25 Compact – name plate ATEX / IECEx, Zone 2
Transmitter unit
Receiver unit
1
Manufacturer
2
Serial number
3
Production date
4
Ex marking
5
Warning: laser class 1
6
Warning: do not open while
energized.
7
Warning – Risk of explosion: de-
energize before opening.
8
Sample component
9
Ambient temperature
0
Power supply
k
Project number
l
Type designation / model
m
Production number
Figure 15: Name plate AO2000-LS25 Compact (example, ATEX / IECEx Zone 2)
Scope of delivery
Component / part
Quantity
Transmitter unit
1 x
Receiver unit
1 x
Connection cable (power supply unit transmitter, transmitter
-
receiver, Ethernet)
every 1 ×
Power supply unit (optional)
1 x
Purging flanges with gaskets (as per order)
2 x
Commissioning Instruction
1 x
Accessories included as per customer order
–
Table 20: Scope of delivery AO2000-LS25
