ABB Arc Guard System TVOC-2 User Manual

Installation
24
Mounting
Introduction This chapter describes the procedure to mount and connect the Arc Monitor.
The procedure is divided into following components:
• Arc Monitor
• Human Machine Interface, HMI
•Detectors
•Extension
• Current Sensing Unit, CSU
Placing Arc Moni-
tor
The Arc Monitor can be mounted anywhere in the switchgear, for example in
the breaker cubicle or in a separate control cabinet.
Mounting Arc
Monitor
This section describes how to mount the Arc Monitor at its location.
The Arc Monitor can be mounted on:
•A wall
•DIN Rail
