Installation
47
Settings
Introduction This chapter describes the five mandatory steps to succeed in setting the
system. All settings are done in the Human Machine Interface, HMI.
Settings are made only with the power on.
Start-Up
Sequence
Installation of the Arc Monitor requires configuration of the system and its
modules to work. This start-up is mandatory. The same start-up occurs
when operating the Arc Monitor for the first time and when adding/removing
modules for the Arc Monitor. The Human Machine Interface (HMI) automati-
cally go through the different configuration steps. To do the Start-Up
sequence follow the steps below:
1. Set language of the system menu
2. Set time and date
3. Confirm connected modules
4. Check DIP Switches
5. Final confirmation
Note!
The system will not require the Start-Up sequence in the event of a power
loss.
Step 1: Setting
menu
language
This is the first step to make the system work after installing the Arc Monitor.
Use this procedure to choose the language of the system menu during start-
up.
In the Start-Up menu do the following:
1. Mark the language to use and press OK.
2. Confirm by pressing YES.
