Electrical connections
Introduction This chapter describes how to connect the electrical connections to the Arc
Monitor and to the Arc Guard System.
Warning!
Make sure that supply voltage is switched off!
Connecting HMI
To read about connecting HMI; See the chapter “Mounting the HMI on door”
on page - 26.
Connecting opti-
cal detector
To read about connecting optical detector ; See the chapter “Connecting
optical detectors” on page - 32.
Connecting exten-
sion module
(option)
To read about connecting extension modules; See the chapter “Connecting
extension module (option)” on page - 33.
Connecting Cur-
rent Sensing Unit
(option)
To read about connecting Current Sensing Unit ; See the chapter “Connect-
ing CSU cable” on page - 34.
