Function Range or value Accuracy
Definite time delay, low step (step 1) at 0
to 1.2 x U
set
(0.00 - 6000.00) s ±0.2% or ±45 ms
whichever is greater
Definite time delay, high step (step 2) at 0
to 1.2 x U
set
(0.000-60.000) s ±0.2% or ±45 ms
whichever is greater
Minimum operate time, Inverse
characteristics
(0.000-60.000) s ±0.2% or ±45 ms
whichever is greater
Operate time, start at 0 to 2 x U
set
Min. = 15 ms
Max. = 30 ms
-
Reset time, start at 2 x U
set
to 0 Min. = 15 ms
Max. = 30 ms
-
Operate time, start at 0 to 1.2 x U
set
Min. = 20 ms
Max. = 35 ms
-
Reset time, start at 1.2 x U
set
to 0 Min. = 5 ms
Max. = 25 ms
-
Critical impulse time 10 ms typically at 0 to 2 x U
set
-
Impulse margin time 15 ms typically -
8.3 Two step residual overvoltage protection
ROV2PTOV
IP14546-1 v4
8.3.1 Identification
SEMOD54295-2 v6
Function description
IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Two step residual overvoltage
protection
ROV2PTOV
2(U0>)
IEC15000108 V1 EN-US
59N
8.3.2 Functionality
M13808-3 v11
Residual voltages may occur in the power system during earth faults.
Two step residual overvoltage protection (ROV2PTOV) function calculates the
residual voltage from the three-phase voltage input transformers or measures it
from a single voltage input transformer fed from an open delta or neutral point
voltage transformer.
ROV2PTOV has two voltage steps, each with inverse or definite time delay.
A reset delay ensures operation for intermittent earth faults.
Section 8 1MRK 506 382-UEN A
Voltage protection
286 Line distance protection REL650 2.2 IEC
Technical manual
