EVENT

BLOCK

^INPUT1

^INPUT2

^INPUT3

^INPUT4

^INPUT5

^INPUT6

^INPUT7

^INPUT8

^INPUT9

^INPUT10

^INPUT11

^INPUT12

^INPUT13

^INPUT14

^INPUT15

^INPUT16

Block

ILRANG

PSTO

UL12RANG

UL31RANG

UL23RANG

3I0RANG

3U0RANG

FALSE

IEC07000065-2-en.vsd

IEC07000065 V2 EN-US

Figure 359: Connection of protection signals for event handling

17.7.4.1 Communication ports

M11880-315 v6

The serial communication module (SLM) is a mezzanine module placed on the first

analog digital conversion module (ADM). It is used for LON, SPA, IEC

60870-5-103 and DNP communication.

In the following figure, X311 ports A/B are for SPA, IEC103 or DNP3 and X311

ports C/D are for LON protocol.

Section 17 1MRK 506 382-UEN A

Station communication

736 Line distance protection REL650 2.2 IEC

Technical manual
