13.11.7 Technical data
GUID-B45901F4-B163-4696-8220-7F8CAC84D793 v1
Table 347: Number of IB16 instances
Function
Quantity with cycle time
3 ms 8 ms 100 ms
IB16 6 4 8
13.12 Integer to Boolean 16 conversion with logic node
representation ITBGAPC
SEMOD158419-1 v3
13.12.1 Identification
SEMOD167944-2 v4
Function description IEC 61850
identification
IEC 60617
identification
ANSI/IEEE C37.2
device number
Integer to boolean 16 conversion with
logic node representation
ITBGAPC - -
13.12.2 Functionality
SEMOD158421-5 v9
Integer to boolean conversion with logic node representation function (ITBGAPC)
is used to transform an integer which is transmitted over IEC 61850 and received
by the function to 16 boolean (logic) output signals.
ITBGAPC function can only receive remote values over IEC 61850 when the R/L
(Remote/Local) push button on the front HMI indicates that the control mode for
the operator is in position R (Remote i.e. the LED adjacent to R is lit), and the
corresponding signal is connected to the input PSTO ITBGAPC function block.
The input BLOCK will freeze the output at the last received value and blocks new
integer values to be received and converted to binary coded outputs.
Section 13 1MRK 506 382-UEN A
Logic
514 Line distance protection REL650 2.2 IEC
Technical manual
