ABB SACE Tmax XT2 User Manual

1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 114
Modules
The Modules menu has several options:
Parameter
Description
Default
Local / Remote
The parameter defines how parameters can be set for units:
 Local: changes parameters only from the display or from the
service connector
 Remote: change parameters only remotely (Ekip Com
modules)
NOTES:
 The Remote mode requires the presence of an
auxiliary power supply and Ekip Com modules,
otherwise it is automatically disabled
 In Remote mode it is still possible to change the
Local/Remote parameter
Local
Local Bus
The parameter allows activation of the communication between the
Trip unit and the modules mounted on the terminal board or
externally to the unit.
Correct communication between units and modules is confirmed by:
 Addition of all the connected modules to the Modules menu
 LED Power of the modules turned on and synchronized like
the Ekip Touch power LED
 No Local Bus alarm in the diagnosis bar
OFF
BLE
BLE activation parameters, see next chapter
Off
-
Menu of each module detected and connected, details from 127
Functions
Access to the functions Switch On LOCAL and RESET signal, see
page 75
BLE
The menu in Settings-Modules allows activating the Bluetooth antenna on the Trip unit, useful
for communicating with an external device (tablet, smartphone) using the BLE protocol, through
the Ekip Connect Mobile app (page 12).
These are the available parameters
Parameter
Description
Default
Enable
Enables/disables the activation of the BT antenna and the
availability of the Battery mode parameter in the menu:
 If On, the BT antenna turns on according to the
configuration of the Battery Mode parameter
 If Off, the antenna is off
Off
Battery mode
Defines the mode for switching on the BT antenna, based on the
presence of devices on the service connector (Ekip T&P, Ekip
Programming, Ekip TT):
Value
BT antenna characteristics
---
On if there are no devices
Off if there are devices
ON
When a device is connected, the antenna is switched off
for 15 seconds and then:
 The antenna remains off if communication with the
device has been activated
 The antenna switches on if communication with
the device has not been activated
IMPORTANT: the typical scenario for configuring
Battery mode = On is: Ekip Touch + Ekip TT +
communication with smartphone active. In all other
cases, including System Update, Battery mode = ---
---
