1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 139
Menu
Activating the local bus is required to start communication between the module and Ekip Touch
and is available in the Settings menu (page 114).
If the module is detected correctly by Ekip Touch two areas are activated:
 information area in the About-Modules menu containing the software version and the serial
number of the module
 area of specific configuration in the Modules Settings menu, in which it is possible to
configure the following communication parameters:
Parameter
Description
Default
MAC
Address
Module address; range from 1 to 63 available
IMPORTANT: devices connected to the same
network must have different directions
63 /
62
(NOTE)
Baudrate
Data transmission speeds: 3 options available:
125 kbit/s, 250 kbit/s, 500 kbit/s
125 kbit/s
NOTE: 63 default of module Ekip Com DeviceNet
TM
; 62 default of module Ekip Com
DeviceNet
TM
Redundant
Remote
configurations
From the service connector (via Ekip Connect) or with communication by system bus it is possible
to access additional parameters:
Parameter
Description
Default
Class ID
Defines the addressing class of the module, between 8
and 16 bit
8-bit Class ID
Bus-Off
behaviour
Defines the behaviour of the module following loss of
communication(Bus-Off), available between Standard (if
the communication is lost, a supply reset is awaited) and
Advanced (the module tries to reset and detects the error
status)
DeviceNet
standard
Remote
information
From the service connector (via Ekip Connect) or with a system bus communication, additional
information is available on the version and the status of the module: HW and Boot version, CRC
status (correctness of SW in the module).
