Configuration
alarms and
suggestions
Below is a list of anomalies that can be viewed on the Ekip Touch display and some suggestions
for resolving them (in alphabetical order):
Signal
Suggestions
Numerical alarm
(e.g. 30002)
Internal error. For this type of error contact ABB
Low battery
Replace the battery (see kit sheet 1SDH001000R0509)
CB status
Incorrect CB status (example: current present but CB status open)
CB undefined
check the circuit breaker status contacts
Configuration
Error of configuration of the protection parameters: verify that the I4
threshold and time t4 are compatible with the minimum values for
self-supply
Configuration session
TFTP server enabled and/or configuration session open on the Ekip
Com IEC61850 or Ekip Hub module.
Contact wear
Check the status of the contacts/poles
Ekip Com Hub
Problem of the Ekip Com Hub module with: certificates, connected
devices, missing Com modules (RTU or with Ethernet connection),
API TLS device, Hub events, parser configuration
Ekip Link Bus
Malfunction of the Ekip Link module: check for loss of connection
with one or more actors
Ekip Signalling 3T
Connection alarm of one or more analog inputs to the Ekip Signaling
3T module
Ethernet disconnected
External cable missing on one or more Ekip Com modules equipped
with Ethernet connection
Internal error
Internal error. For this type of error contact ABB.
Invalid date
Incorrect date and time: set in the menus Settings-System-Date and
Settings-System-Time
IEEE1588 synch
Synchronization problem of the IEEE 1588 synchronization module
Local Bus
Unit turned on with auxiliary power supply, Local Bus parameter
enabled but connection to modules not present, incorrect, or
communication lost (for more than five seconds). Check:
 connection and startup of the terminal or external modules
 that the connected modules are compatible with Ekip Touch
 that the Local Bus parameter is: ON (see page 29)
MAC address
Ekip Com module with wrong/unacceptable MAC address detected
Maintenance
Maintenance alarm: check if the set maintenance interval has been
reached
PC Power exceed
The average power limit set for the Power Controller has been
exceeded
Zone Selectivity Diag
Error in zone selectivity connections (Selectivity Hardware)
Sensor L1/L2/L3/Ne
Malfunction in the connection of the sensors to the Trip unit. Check
the status of the power sensors and the correct connection of the
external Neutral sensor
SNTP error
Malfunction with Ekip Com modules: synchronization problem of the
SNTP synchronization module
Switchboard Actor
communication Error
Verify the configuration and connection of the Ekip Link module
TC disconnected
Disconnection of the Trip coil disconnected, verify its operation
