ABB SACE Tmax XT2 User Manual

1SDH002031A1002 ECN000092998 Rev. B SACE Tmax XT2 – XT4 | 29
Settings Menu
Menu
Submenu
Description and parameters
Page
Circuit breaker
Configuration
(1)
Description in the dedicated chapter
113
Hardware Trip
Description in the dedicated chapter
44
Protection T
Description in the dedicated chapter
44
Neutral Protection
(2)
Function parameters and commands: see
the details in the dedicated chapter
41
Grid frequency
--
Grid frequency configuration
113
Phase sequence
--
Phase sequence configuration
48
Modules
Local/Remote
Parameter save configuration
114
Local Bus
Local bus presence configuration
114
Module x
(3)
Details in the chapters of each module
114
BLE
BT communication configuration
114
Functions
Switch On LOCAL, RESET alert
114
Measurement range
--
Measurement interval configuration
98, 114
Bus Test
--
Enable bus test
115
Power Controller
(4)
Enable
(5)
Function enabling and parameters: see the
details in the dedicated chapter
121
-
Load Shedding
(4)
Enable
(5)
Function enabling and parameters: see the
details in the dedicated chapter
122
-
Network Analyzer
(6)
Enable
(5)
Function enabling and parameters: see the
details in the dedicated chapter
106
-
Datalogger
(6)
Enable
(5)
Function enabling and parameters: see the
details in the dedicated chapter
104
-
Dual Setting
(6)
Enable
(5)
Enable function
65
Default setting
Default setting configuration
System
Data
Unit date configuration
115
Time
Unit time configuration
Language
Menu language configuration
New password
Password configuration
View
Client page
Description in the dedicated chapter
115
Display contrast
--
Description in the dedicated chapter
115
Functions
YO Command
Function, Delay
75, 74
YC Command
Function, Delay
Maintenance
Alerts
Enable maintenance alerts
99, 115
MLRIU
(7)
-
Motor protection parameters: see the details
in the dedicated chapter
66
NOTES:
(1) Available with CB in 3P configuration
(2) Available with CB in 4P or 3P + N configuration
(3) The menu is populated with the list of accessory modules detected by units with
Local Bus enabled and connected and powered as required
(4) Available if the function is installed on a Trip unit
(5) The list of the specific submenu is only populated with the function enabled (= On)
(6) Available if required by the Trip unit model or if the relative software package has
been enabled
(7) Available with Ekip M Touch
