Test Menu
Menu
Submenu
Description, parameters, and
commands
Page
Self-test
--
Self-test command
119
Trip Test
--
TRIP command
119
CB Test
--
Close CB, Open CB
119
Ekip CI
--
Self-test command
119
Ekip Signalling
2K
(1)
Ekip Signalling 2K-1
(1)
Module self-test command
120
Ekip Signalling 2K-2
(1)
Module self-test command
Ekip Signalling 2K-3
(1)
Module self-test command
Zone selectivity
(2)
S Protection
(3)
Inputs, Force Output, Release Output
120
G Protection
(4)
Inputs, Force Output, Release Output
NOTES:
(1) available if one or more Ekip Signalling 2K modules are connected and detected by Ekip
Touch
(2) Available if Ekip Touch is switched on with auxiliary power supply
(3) Available with S and/or S2 protection enabled and curve t = k
(4) Available with G protection enabled and curve t = k
Information Menu
Menu
Submenu
Information included
Protection unit
--
Ekip Touch information: Mainboard serial number, Trip unit
serial number, type, version, regulation, software version,
date and time, language
Circuit breaker
--
CB Information: TAG name, CB name, rated power, number
of poles, CB status and position, total operations
IEC61557-12
(1)
--
Measurements status 1% (from the Class 1 Power & Energy
Metering package), serial numbers of the assembly and
connected power sensors
Feature Collection
--
List of protections enabled on the Trip unit
Modules
Module x
(2)
Module information: serial number, SW version,
input/output/contact status (if any)
Power Controller
(3)
Load Input Status
Load status (open/closed)
Active load
Load configuration (active/inactive)
Load shedding
(3)
Load Input Status
Load status (open/closed)
Active load
Load configuration (active/inactive)
NOTES:
(1) Available if the Class 1 Power & Energy Metering SW package is required by the Trip unit
model or if it has been previously enabled
(2) Available if one or more modules are connected and detected by the unit
(3) Available if the function is installed and enabled on a Trip unit
