Service and Maintenance
5-103
LCD Panel Bracket Installation
1.
Attach the six (6) screws to secure
the LCD pane
l bracket
s to the LCD panel.
Figure 5:158. Inst
alling the LCD Panel Bracket
s
2.
Install the LCD panel (see
LCD Panel Inst
allati
on
on page
5-98
).
T
able 5:21. LCD Panel Bracket Screws
Screw Name
Screw T
ype
Quantity
M 2.0 x 3.0
6
