1 Publication 1769-UM009B-EN-P - May 2002
Appendix
A
Specifications
This appendix contains the product specifications for the 1769-SDN
DeviceNet Scanner Module.
General Specifications
For information about See page
General Specifications A-1
Electrical and DeviceNet Specifications A-2
Dimension Drawings A-3
Compact I/O with CompactLogix Controller and Power Supply A-3
Compact I/O with MicroLogix 1500 Base Unit and Processor A-3
Specification Value
Module Dimensions 118 mm (height) x 87 mm (depth) x 35 mm (width)
height including mounting tabs is 138 mm
4.65 in. (height) x 3.43 in (depth) x 1.38 in (width)
height including mounting tabs is 5.43 in.
Approximate Shipping Weight
(with carton)
280g (0.61 lbs.)
Storage Temperature -40°C to +85°C (-40°F to +185°F)
Operating Temperature 0°C to +60°C (32°F to +140°F)
Operating Humidity 5% to 95% non-condensing
Operating Altitude
2000 meters (6561 feet)
(1)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 inches maximum
peak-to-peak
Shock Operating: 30G panel mounted (20G DIN rail mounted)
Non-Operating: 40G panel mounted (30G DIN rail
mounted)
Agency Certification
• C-UL certified (under CSA C22.2 No. 142)
• UL 508 listed
• CE and C-Tick compliant for all applicable
directives
• ODVA DeviceNet conformance tested
Hazardous Environment Class Class I, Division 2, Hazardous Location, Groups A, B, C,
D (UL 1604, C-UL under CSA C22.2 No. 213)
Radiated and Conducted Emissions EN50081-2 Class A
