Publication 1769-UM009B-EN-P - May 2002
DeviceNet I/O Image 5-9
Output Data Image
The Output Data Image can be up to a 180 word array. The
controllers output data will be delivered across DeviceNet to the
destination slave devices. The scanner’s scanlist configuration will
determine how this data is actually sent to the slave device (polled,
cyclic, or change of state).
Slave mapping is done using RSNetWorx.
Table 5.14 Output Data Image
Output Word Description
2 to 181 DeviceNet Slave output and/or master input data
