1 Publication 1769-UM009B-EN-P - May 2002
Chapter
3
Installation and Wiring
This chapter describes how to install and wire the 1769-SDN scanner
module. The following table describes what this chapter contains and
where to find specific information.
Compliance to European
Union Directives
This product is approved for installation within the European Union
and EEA regions. It has been designed and tested to meet the
following directives.
EMC Directive
The module is tested to meet Council Directive 89/336/EEC
Electromagnetic Compatibility (EMC) and the following standards, in
whole or in part, documented in a technical construction file:
• EN 50081-2
EMC – Generic Emission Standard, Part 2 - Industrial
Environment
• EN 50082-2
EMC – Generic Immunity Standard, Part 2 - Industrial
Environment
This product is intended for use in an industrial environment.
For information about See page
Compliance to European Union Directives 3-1
Power Requirements 3-2
General Considerations 3-3
System Planning 3-5
System Assembly 3-6
System Mounting 3-7
Replacing the Scanner Module within a System 3-10
Field Wiring Connections 3-11
Scanner Module Power-Up 3-12
What’s Next? 3-12
