Publication 1756-UM001G-EN-P - January 2007
Directly Connect to the Controller via the Serial Port 17
Configure the Serial Driver
Use RSLinx software to configure the RS-232 DF1 Device driver for
serial communication.
To configure the driver, perform this procedure.
1. From the Communications pull-down menu in RSLinx software,
choose Configure Drivers.
The Configure Drivers dialog appears.
2. From the Available Driver Types pull-down menu, choose the
RS-232 DF1 Device driver.
3. Click Add New.
The Add New RSLinx Driver dialog appears.
4. Type the driver name and click OK.
