Publication 1756-UM001G-EN-P - January 2007
62 Place, Configure, and Monitor I/O Modules
EtherNet/IP I/O Considerations
When you add EtherNet/IP I/O at runtime:
• the EtherNet/IP I/O modules you add at runtime use can be:
– added to existing rack-optimized connections.
– added to new rack-optimized connections.
– added as direct connections.
You can create new rack-optimized connections when adding
EtherNet/IP I/O modules at runtime.
• you can add I/O modules until you reach the limits of the
communication module.
Additional Resources
For additional information, consult the EtherNet/IP Performance
Application Guide, publication ENET-AP001.
Module Type Pulses per
Second, Max
TCP
Connections,
Max
CIP
Connected
Messages,
Max
Connected
Bridged
Messages,
Max
Connected
End Node
Messages,
Max
Unconnected
Messages,
Max
1756-ENBT 4500
64
128
128 32
256
1756-ENET,
Series B
810 160 64
