54 Place, Configure, and Monitor I/O Modules
Place Local I/O Modules
Your choice of 1756 chassis determines how many local I/O modules
you can use. You can fill your chassis’ slots with any combination of
controllers, communication modules, and I/O modules.
Available Chassis Slots
For empty slots, use the 1756-N2 slot-filler module.
The ControlLogix controller also supports distributed (remote) I/O via
these networks:
• EtherNet/IP
• ControlNet
• DeviceNet
• Universal remote I/O
Additional Resources
For additional information, consult these publications:
• ControlLogix Digital I/O Modules User Manual, publication
1756-UM058
• ControlLogix Analog I/O Modules User Manual, publication
1756-UM009
Chassis Available Slots
1756-A4 4
1756-A7 7
1756-A10 10
1756-A13 13
1756-A17 17
