176 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Load current,
continuous, max
2.0 A 100 mA (high-speed
operation)
1.0 A @ 30 °C
0.3 A @ 65 °C
(standard operation)
1.0 A @ 30 °C
0.3 A @ 65 °C (standard
operation)
Surge current, per point See Relay Contacts
Ratings on page 166
4.0 A for 10 ms every 1 s @ 30 °C; every 2 s @
65 °C
(1)
Current, per common,
max
5 A – –
Turn on time/
Turn off time, max
10 ms 2.5 μs0.1 ms
1 ms
(1) Applies for general purpose operation only; does not apply for high-speed operation.
Relay Contacts Ratings
Maximum Volts Amperes Amperes
Continuous
Volt-Amperes
Make Break Make Break
120V AC 15 A 1.5 A 2.0 A 1800V A 180V A
240V AC 7.5 A 0.75 A
24V DC 1.0 A 1.0 A 28V A
125V DC 0.22 A
Environmental Specifications
Attribute Value
Temperature, operating IEC 60068-2-1 (Test Ad, Operating Cold),
IEC 60068-2-2 (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20…65 °C (-4…149 °F)
Temperature, surrounding
air, max
65 °C (149 °F)
Temperature, non-operating IEC 60068-2-1 (Test Ab, Unpackaged Nonoperating Cold),
IEC 60068-2-2 (Test Bb, Unpackaged Nonoperating Dry Heat),
IEC 60068-2-14 (Test Na, Unpackaged Nonoperating Thermal Shock):
-40…85 °C (-40…185 °F)
Relative humidity IEC 60068-2-30 (Test Db, Unpackaged Damp Heat):
5…95% non-condensing
Vibration IEC 60068-2-6 (Test Fc, Operating):
2 g @ 10…500 Hz
Shock, operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
25 g
Shock, non-operating IEC 60068-2-27 (Test Ea, Unpackaged Shock):
DIN mount: 25 g
PANEL mount: 35 g
Emissions CISPR 11
Group 1, Class A
Output Specifications
Attribute 2080-LC50-24QWB
2080-LC50-24AWB
2080-LC50-24QVB / 2080-LC50-24QBB
Relay Output Hi-Speed Output
(Outputs 0...1)
Standard Output
(Outputs 2 and higher)
