182 Rockwell Automation Publication 2080-UM002G-EN-E - March 2015
Appendix A Specifications
Enclosure type rating Meets IP20
Wire size 0.32... 2.1 mm² (22...14 AWG) solid copper wire or
0.32... 1.3 mm² (22...16 AWG) stranded copper wire
rated @ 90 °C (194 °F ) insulation max
Terminal screw torque 0.5…0.6 Nm (4.4…5.3 lb-in.)
(using a Phillips-head or 2.5 mm (0.10in.) flat-blade screwdriver)
Wiring category
(2)
2 – on power ports
Insulation stripping length 7 mm (0.28 in.)
North American temp code T4A
(1) Any fluctuation in voltage source must be within 85V...264V. Do not connect the adapter to a power source that
has fluctuations outside of this range.
(2) Use this Conductor Category information for planning conductor routing. Refer to Industrial Automation Wiring
and Grounding Guidelines, publication 1770-4.1
.
General Specifications
Attribute Value
