Appendix E Troubleshooting
0xF300 The memory module is empty. Perform one of the following:
• Check to make sure there is a valid project in the memory module.
• Download a user program and use the backup function to the memory
module.
0xF301 The memory module’s project is not compatible
with the controller.
Perform one of the following:
• Check to make sure there is a user program with a controller that has the
correct controller catalog configured.
• Download a user program and use the backup function to the memory
module.
0xF302 The password is mismatched. Perform one of the following:
• Check to make sure that the user program in the memory module has the
correct password.
• Download a user program with a password and use the backup function to
the memory module.
• Use Connected Components Workbench to enter the correct password into
the controller and perform the restore operation again.
0xF303 The memory module is not present. Check to make sure the memory module is present.
For the following four error codes, z is the slot number of the plug-in module. If z = 0, then the slot number cannot be identified
0xF0Az The plug-in I/O module experienced an error
during operation.
Perform one of the following:
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
• If the error persists, see the Micro800 Plug-In Modules, publication 2080-
UM004.
0xF0Bz The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform one of the following:
• Correct the plug-in I/O module configuration in the user program to match
that of the actual hardware configuration.
• Check the condition and operation of the plug-in I/O module.
• Cycle power to the Micro800 controller.
• Replace the plug-in I/O module.
• If the error persists, see the Micro800 Plug-in Modules, publication
2080-UM004
.
0xF0Dz When power was applied to the plug-in I/O
module or the plug-in I/O module was removed, a
hardware error occurred.
Perform the following:
1. Correct the plug-in I/O module configuration in the user program.
2. Build and download the program using Connected Components Workbench.
3. Put the Micro800 controller into Run mode.
0xF0Ez The plug-in I/O module configuration does not
match the actual I/O configuration detected.
Perform the following:
1. Correct the plug-in I/O module configuration in the user program.
2. Build and download the program using Connected Components Workbench.
3. Put the Micro800 controller into Run mode.
List of Error Codes for Micro800 controllers
Error Code Description Recommended Action
