TP8 DIAG_3 OIB A, RX4 Diagnostic Feedback
TP9 CMD_3 OIB A, TX4 Firing Command Signal
TP10 DIAG_4 OIB A, RX5 Diagnostic Feedback
TP11 CMD_4 OIB A, TX5 Firing Command Signal
TP12 DIAG_5 OIB A, RX6 Diagnostic Feedback
TP13 CMD_5 OIB A, TX6 Firing Command Signal
TP14 TFB_A OIB A Temperature Feedback Signal
TP15 GND Ground Reference for TP1 – TP14
TP16 DIAG_6 OIB B, RX1 Diagnostic Feedback
TP17 CMD_6 OIB B, TX1 Firing Command Signal
TP18 DIAG_7 OIB B, RX2 Diagnostic Feedback
TP19 CMD_7 OIB B, TX2 Firing Command Signal
TP20 DIAG_8 OIB B, RX3 Diagnostic Feedback
TP21 CMD_8 OIB B, TX3 Firing Command Signal
TP22 DIAG_9 OIB B, RX4 Diagnostic Feedback
TP23 CMD_9 OIB B, TX4 Firing Command Signal
TP24 DIAG_10 OIB B, RX5 Diagnostic Feedback
TP25 CMD_10 OIB B, TX5 Firing Command Signal
TP26 DIAG_11 OIB B, RX6 Diagnostic Feedback
TP27 CMD_11 OIB B, TX6 Firing Command Signal
TP28 TFB_B OIB B Temperature Feedback Signal
TP29 GND Ground Reference for TP16 – TP28
TP30 DIAG_12 OIB C, RX1 Diagnostic Feedback
TP31 CMD_12 OIB C, TX1 Firing Command Signal
TP32 DIAG_13 OIB C, RX2 Diagnostic Feedback
TP33 CMD_13 OIB C, TX2 Firing Command Signal
TP34 DIAG_14 OIB C, RX3 Diagnostic Feedback
TP35 CMD_14 OIB C, TX3 Firing Command Signal
TP36 DIAG_15 OIB C, RX4 Diagnostic Feedback
TP37 CMD_15 OIB C, TX4 Firing Command Signal
TP38 DIAG_16 OIB C, RX5 Diagnostic Feedback
TP39 CMD_16 OIB C, TX5 Firing Command Signal
TP40 DIAG_17 OIB C, RX6 Diagnostic Feedback
TP41 CMD_17 OIB C, TX6 Firing Command Signal
TP42 TFB_C OIB C Temperature Feedback Signal – There is no provision in the drive
for the use of this signal, it is only provided for Rockwell internal testing.
TP43 GND Ground Reference for TP30 – TP42
Test Point Signal Name Description
To Next Page
