5. Locate the desired number in the first column of Table 4 on
the following page.
6. Press the DELICATES (∧) or the COLD (∨) keypad to in-
crease or decrease the current number until correct.
For Example: A user might wish to have the signal sound only
when a keypad is pressed. Entering the number “1” in step 5
would turn off all the options except KEYPAD. In this instance,
the signal would sound only when a keypad is pressed.
7. Press the START (enter) keypad when the correct number ap-
pears in the display. The next option will appear in the dis-
play.
How to Read Audio Signal Table
To determine the correct number required to program the Audio
Signal, use the following chart. The Signal Value column con-
tains the number displayed on the control. The other columns cor-
respond to individual options.
Each column of options contains a unique combination of the
words “ON” and “OFF” that indicates if that column’s option is
turned on or off when the Signal Value is entered. Select the de-
sired combination of options and enter the number found in the
Signal Value column.
The default value programmed at the factory is 29.
Signal Value Start Mode
Serial or Net-
work Vending
Command
Signal
Coin/Card In-
put End of Cycle Key Pressed
0 OFF OFF OFF OFF OFF
1 OFF OFF OFF OFF ON
2 OFF OFF OFF ON OFF
3 OFF OFF OFF ON ON
4 OFF OFF ON OFF OFF
5 OFF OFF ON OFF ON
6 OFF OFF ON ON OFF
7 OFF OFF ON ON ON
8 OFF ON OFF OFF OFF
9 OFF ON OFF OFF ON
10 OFF ON OFF ON OFF
11 OFF ON OFF ON ON
12 OFF ON ON OFF OFF
13 OFF ON ON OFF ON
14 OFF ON ON ON OFF
15 OFF ON ON ON ON
16 ON OFF OFF OFF OFF
Table 4 continues...
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
43 Part No. 204370ENR1
