Signal Value Start Mode
Serial or Net-
work Vending
Command
Signal
Coin/Card In-
put End of Cycle Key Pressed
17 ON OFF OFF OFF ON
18 ON OFF OFF ON OFF
19 ON OFF OFF ON ON
20 ON OFF ON OFF OFF
21 ON OFF ON OFF ON
22 ON OFF ON ON OFF
23 ON OFF ON ON ON
24 ON ON OFF OFF OFF
25 ON ON OFF OFF ON
26 ON ON OFF ON OFF
27 ON ON OFF ON ON
28 ON ON ON OFF OFF
29* ON ON ON OFF ON
30 ON ON ON ON OFF
31 ON ON ON ON ON
* Factory default setting.
Table 4
Network Node Number nodE
This option allows the owner to program a unique number used
for wired or wireless communication. Every machine on the same
network much have a different node number to work correctly.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2. Press the DELICATES (∧) or the COLD (∨) keypad until
Prog appears in the display. Press the START (enter) keypad,
and AtS 1 will appear in the display.
3. Press the DELICATES (∧) or the COLD (∨) keypad to scroll
through the programmable options until nodE appears in the
display.
4.
When nodE appears in the display, press the START (enter)
keypad. The current Network Node Number status will appear
in the display.
5. Press the DELICATES (∧) or the COLD (∨) keypad to change
the current status.
6. Press the START (enter) keypad when the correct value ap-
pears in the display. The new value is saved and the next op-
tion will appear in the display.
Error Code Programming Error-
This option allows the owner to turn on or turn off certain errors
in the control.
1. Control must be in Manual Mode. Refer to How to Enter the
Manual Mode.
2. Press the DELICATES (∧) or the COLD (∨) keypad until
Prog appears in the display. Press the START (enter) keypad,
and AtS 1 will appear in the display.
3. Press the DELICATES (∧) or the COLD (∨) keypad to scroll
through the programmable options until Error- appears in
the display.
Programming Control
©
Copyright, Alliance Laundry Systems LLC -
DO NOT COPY or TRANSMIT
44 Part No. 204370ENR1
To Next Page
