Removing the stator
- Remove the 2 Pick-Up screws and the one for
the wiring bracket as well as the 3 stator fixing
screws shown in the figure.
- Remove the stator and its cable harness.
Locking torques (N*m)
Screws fixing freewheel to flywheel 13÷15 (9.6÷11.1 ftlb)
Refitting the stator
- Refit the stator and the flywheel carrying out the
removal steps but in reverse order, tightening the
retainers to the prescribed torque.
Locking torques (N*m)
Stator unit screws 3÷4 (2.2÷3 ftlb) (Apply LOCTITE 242 medium-strength threadlock)
ATLANTIC 300 i.e. Engine
ENG - 119
