Unscrew and remove the two screws
«4» fixing the light lower support
•
Unscrew and remove the four screws
«5» fixing the instrument panel - top
fairing support to the chassis.
•
Remove the instrument panel - top fair-
ing support
Locking torques (N*m)
Screw fixing support to chassis 10 ± 20% (7.4 ftlb)
Lower cover
•
Park the vehicle on its centre stand.
•
Operating from both sides, remove the
rear mat by lifting it with the hands.
•
Operating from both sides, unscrew
and remove the seven screws «1».
Chassis ATLANTIC 300 i.e.
CHAS - 268
