Front mudguard
•
Park the vehicle on its centre stand.
•
Operating from both sides, undo and
remove the two screws «1».
•
Remove the front mudguard.
Locking torques (N*m)
Front mudguard fixing screw 7 (5.2 ftlb)
Fuel tank
FUEL PROBE REMOVAL
•
Remove the central tunnel.
•
Disconnect the delivery pipe and the
fuel return pipe «1».
•
Disconnect the fuel probe connector
«2».
•
Undo and remove the ring nut «3».
ATLANTIC 300 i.e. Chassis
CHAS - 263
