Coolant replacement
RADIATOR REMOVAL
•
Drain off the system.
•
Remove the lower protection.
•
Disconnect the electric fan connector.
•
Disconnect the two thermal switch con-
nectors.
•
Operating from both sides, cut the
clamp «1».
•
Slide off both air deflectors from the ra-
diator.
•
Operating from both sides, undo and
remove the two screws «2».
•
Undo and remove the central screw
«3».
•
Remove the clamps.
Cooling system ATLANTIC 300 i.e.
COOL SYS - 234
