Centre-stand
CENTRE STAND REMOVAL
•
Place the vehicle on its side stand.
•
Disconnect the two springs.
•
Unscrew and remove the nut «1».
•
Slide off the screw from the opposite
side.
•
Remove the centre stand.
CAUTION
GREASE SLIP BANDS AND BE CAREFUL NOT TO DAM-
AGE THE SEALING RINGS DURING REFITTING. TIGHTEN
THE NUT AND CHECK THE CORRECT STAND RETURN.
Locking torques (N*m)
Nut fixing centre stand to engine 28 ± 20% (20.7 ftlb)
Side stand
•
Remove the central tunnel.
•
Disconnect the connector from the side
stand.
Suspensions ATLANTIC 300 i.e.
SUSP - 216
