License plate light
LICENSE PLATE LIGHT BULB REPLACEMENT
•
Grip the bulb holder «10», pull and take
it out from its fitting.
•
Slide off and replace the bulb with one
of the same type.
Side fairings
•
Remove the front closing.
•
Remove the legshield.
•
Operating from both sides, undo and
remove the upper screw «1».
NOTE
THE OPERATIONS DESCRIBED BELOW REFER TO RE-
MOVING ONLY ONE FAIRING BUT APPLY TO BOTH.
•
Operating from both sides, undo and
remove the screw «2».
•
Unscrew and remove the four screws
«3».
•
Remove the fairing.
Chassis ATLANTIC 300 i.e.
CHAS - 256
