Rear mudguard
•
Undo and remove the two screws fixing
the filter case «1».
Locking torques (N*m)
Screw fixing filter case to engine 8 ± 20% (5.9 ftlb)
•
Undo and remove the three fixing
screws «2» and collect the cable guide.
•
Remove the rear mudguard.
Locking torques (N*m)
Screw fixing rear mudguard to engine 10 ± 20% (7.4 ftlb)
Helmet bay
•
Remove the tail section.
•
Remove the saddle.
•
Remove the battery and slide off the
main fuse boxes.
•
Unscrew and remove the two front
screws «1».
ATLANTIC 300 i.e. Chassis
CHAS - 261
