APRILIA Atlantic 300 User Manual

1. Complete wheel
2. Seeger
3. Bearing
4. Brake calliper and muffler supporting plate
5. Nut
CHECKS
Check according to the instructions on the sched-
uled maintenance table.
•
Rest the vehicle on its centre stand.
•
Turn the wheel manually towards on
direction and another.
•
Check that the wheel turns smoothly,
without obstacles and/or noise, other-
wise replace the bearings. .
•
If the wheel oscillates during rotation,
check the affected components.
•
If the wheel stops at the same point ev-
ery time after rotating it several times,
proceed with balancing.
Removing the rear wheel
•
Remove the exhaust.
•
Remove the rear mudguard.
•
Slide off the rear brake calliper, keep-
ing it linked to the oil pipe.
•
Undo and remove the screw «1».
Locking torques (N*m)
Muffler plate-engine fixing screw 25 ± 20% (18.5 ftlb)
ATLANTIC 300 i.e. Suspensions
SUSP - 211
