Measure the pin hole diameter (2) and
replace the piston and the pin all to-
gether if not complying with specifica-
tions
Characteristic
Pin hole diameter on piston
15.002 / 15.008 mm (0.5906 / 0.5909 in)
Installing the cylinder
•
With the special tool, tighten the piston
rings of the piston and insert it in the
cylinder sliding it downwards.
Specific tooling
020287Y tool for sealing ring fitting
Crankcase - crankshaft
ETX - STX 150 Engine
ENG - 107
