Remove the two fixing screws (3) of the
chain tensioner
•
Remove the chain tensioner (4)
Chain removal
•
Remove the camshaft timing system
gear cover and the gear
•
Remove the chain tensioner
•
Remove the alternator crankcase, the
complete alternator and the spacer to
be able to access the safety plate for
the chain
•
Remove the fixing screw (1) of the
plate
•
Remove the plate (2)
ETX - STX 150 Engine
ENG - 99
