Remove the gasket (3)
Removing the crankshaft
•
Open the crankcase
•
Remove the crankshaft from the free-
wheel side crankcase
Removing the countershaft
•
Using an aluminium lock, place it in the
indicated zone and lock the gears
•
Remove the locking ring nut (1) of the
timing system gear connected to the
countershaft
•
Detach the crankcase
•
Remove the countershaft (2)
ETX - STX 150 Engine
ENG - 109
