Remove the two screws and the rela-
tive washers (3) fixing the internal part
of the dashboard (4) and remove it
•
Remove the clamp (5) that fastens the
front light assembly wiring
•
Remove the two screws (6) fixing the
front light assembly to the frame
•
Disconnect the low/high beam light
connectors (7), the speedometer con-
nector (8), the turn indicator connec-
tors (9), the instrument panel connec-
tor (10)
•
Remove the front light assembly and
the frame with the instrument panel.
REMOVING THE INSTRUMENT PANEL
ETX - STX 150 Bodywork
BODYW - 147
