Lift the protection casing (1)
HOLD THE REAR-VIEW MIRROR (4) TO AVOID DROPPING IT BY ACCIDENT.
•
Keep the screw (2) blocked and com-
pletely unscrew the nut (3).
HANDLE PLASTIC AND PAINTED COMPONENTS WITH
CARE, DO NOT SCRATCH OR SPOIL THEM.
•
Remove the rear-view mirror (4).
CAUTION
REPEAT THE PROCEDURE TO REMOVE THE OTHER MIRROR.
AFTER REFITTING, ADJUST THE REAR-VIEW MIRRORS CORRECTLY AND TIGHTEN THE NUTS
IN ORDER TO ENSURE STABILITY.
After refitting:
•
Adjust the rear-view mirror angle correctly.
Headlight assy.
WINDSHIELD REMOVAL
•
Remove the four screws (1) fixing the
top fairing
ETX - STX 150 Bodywork
BODYW - 145
