Rimozione rotore
CONNECTING ROD-PISTON UNIT
pos.
Description Type Quantity Torque Notes
1 Flywheel fixing screw M10x36 1 55 +/- 5 Nm (40.57 +/-
3.69 lb ft)
-
•
Place the specific rotor lock tool and fit
with the screws with the protrusion as
indicated in the figure
Specific tooling
020970Y Flywheel retainer
•
Remove the rotor fixing screw
Engine ETX - STX 150
ENG - 76
