SBS COSMOS REFRIGERATOR 07.11.2018 / REV NO: 01
18
Sensitivity: Public
5.3. Appropriate installation location
WARNING: If the door of the room in which the refrigerator shall be
installed is too narrow for the passage of product, doors of the unit
should be removed and passed through in a horizontal position.
Install your product to a place that allows ease of use.
Your product should be installed at least 30 cm away from heat sources such as
hobs, ovens, central heaters and stoves and at least 5 cm away from electrical ovens.
It should not be exposed to humidity and direct sunlight after installation.
There must be appropriate air circulation around your product in order to achieve an
efficient operation. If the refrigerator is to be placed in a recess in the wall, there must
be at least 5 cm clearance with the ceiling and side walls.
Do not place the product on materials such as carpet or rugs.
Place the refrigerator on a flat surface to avoid any jolts.
Do not install the product in the environments where the temperature falls below
10°C.
If two coolers are to be installed side by side, there should be at
least 4 cm distance between them.
5.4. Installing the plastic wedges
Plastic wedges are used in order to maintain the clearance that shall provide the air
circulation between the product and the wall. Insert the 2 plastic wedges supplied with the
product onto the rear ventilation cover as illustrated in the figures. In order to attach the
wedges, remove the screws on the product and use the screws found in the same pouch
with the wedges.
5.5. Electric connection
Connect the product to a grounded socket which is protected by a fuse conforming to the
To Next Page
