arcelik BEKO G91632NE User Manual

SBS COSMOS
REFRIGERATOR 10.01.2014 / REV NO: 03
83
Sensitivity: Public
12.30. DC_Panasonic Condenser fan
Service numbers used:
1705 condenser fan
1353 fan blade
836 evaporation container
53 Coil condenser
1
2 3
• Remove 1 piece of PT 4x16 screw of the coil condenser by using a Phillips screwdriver.
• Remove 3 pcs of delta PT K4x20 screws by using a Phillips screwdriver.
• Remove the fan from its housing.
• Do not damage the wings when attaching the fan blade (propeller).
