• Icematic group is located in the upper part of the freezer door.
• Hold the ice stock container group by the handles at sides to move upwards and
remove it.
• Move the icematic decorative cover upwards and remove it.
• While replacing the ice stock container, care should be paid not to coincide the motor
rotation group steps with each other.
12.49. Ice making area connections
Service numbers used:
1084 Icematic socket cover
• Unscrew the phillips screw on the right of the socket cover.
• Remove the socket cover backwards to remove it.
