SBS COSMOS REFRIGERATOR
07.11.2018 / REV NO: 01
22
Sensitivity: Public
WARNING: Make sure that the “Ice Off” mode is active before
taking out the by-pass cover.
WARNING: Water filter cleans some foreign particles contained in
the water. It does not purify the water from microorganisms.
WARNING: “Ice Off” button must always be pressed during replacement of
the water filter or when installing the by-pass cover.
It is normal that a few drops of water drip after the cover has been taken out.
Water filter should be replaced every 6 months. Remove the water filter and
install the bypass cover as shown in the figure when you replace the water
filter or when it will no longer be used. Make sure that the “Ice Off” mode is
active before taking out the filter.
6.3. Connecting the water pipe to the cold water mains line
If you will use the refrigerator by connecting it to the mains cold water supply, you need to
connect a standard 1/2" valve fitting to the mains cold water supply in your house.
WARNING: Secure the water pipe to suitable points by means of
the clips supplied to avoid any damage or displacement or
accidental disconnection.
WARNING: After turning on the water valve, make sure that there
is no leakage at both connection points of the water pipe. In case
of a leak, turn off the valve immediately and tighten all joints again
using a pipe wrench or pliers.
WARNING: Make sure that standard 1/2" valve fitting fed by cold
mains water supply is available and is turned off fully.
1 2 3
Remove the water valve union as in Picture 1 and reattach it to the water valve by
installing it onto the water pipe.
Remove the tap adaptor and attach the union instead as in Picture 2.
Connect the standard 1/2" valve connection fitting to the union.
To be connected to
the cold water line
To Next Page
