arcelik BEKO G91632NE User Manual

SBS COSMOS
REFRIGERATOR 10.01.2014 / REV NO: 03
89
Sensitivity: Public
12.35. PTC Relay (Combo unit )
Service numbers used:
43 combo unit (PTC Relay)
44 thermic protector
• Combo unit and thermic protector are used at the lateral part of the compressor.
• When the temperature increases, thermic trips and disconnects the circuit and stops
the operation of the refrigerator.
12.36. Capacitor
Used service number: 48
• Capacitor is assembled behind the compressor.
• Release it from the bottom tabs by turning to right and left, and remove.
combo
unit
thermic
